Phoenix Contact 1757048 PCB connector MSTB 2,5/ 5-ST-5,08
Normally In Stock
Code: 145868
Phoenix Contact 1757048 MSTB 2,5/ 5-ST-5,08 ,Copper Alloy,PA,I Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day $5.68
Sale Price
$4.73
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1757048 The PCB connector, identified by its green color and nominal cross-sectional area of 2.5mm², is rated for a maximum current flow of 12A at a voltage of up to 320V (III/2). The contact surface material is tin, with a socket connection type and five potentials available per row. The connector has a pitch of 5.08mm, featuring screw connections secured by tension sleeves, and is designated as the MSTB 2,5/...-ST product range.
Specifications
Connector Amperage
12 Amp
Connector Voltage
4 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Sub Component
PCB Terminal Block
Connector Voltage
.21 Kv
Number of Connections
5
Number of Positions
5
Component
PCB
Connector Voltage
320 Volt
Connector Voltage
250 Volt
Connector Voltage
630 Volt
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
