Schneider Electric TM171EP27R Modicon M171 Performance expansion 27 I/Os
Normally In Stock
Code: 110922
Schneider TM3DI32K 32 Discrete input module 32 input IEC 61131-2 Type 1 24 V HE-10 connector for inputs Top hat type TH35-15 rail IEC 60715, Top hat type TH35-7.5 rail IEC 60715, plate or panel with fixing kit IP20 with protective cover in place Input/Output (I/O) modules for PLC
Condition: New
CALL FOR LEAD TIME$442.51
Sale Price
$368.76
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Modicon M171 Performance expansion 27 I/Os
Specifications
(Modicon PLC) Analog Input Type
Current 4-20 Ma
(Modicon PLC) Digital Inputs
8
(Modicon PLC) Analog Input Type
Voltage 0-5 V
(Modicon PLC) Digital Outputs
3 Relay Outputs SPST With Same Common
(Modicon PLC) Digital Outputs
2 Relay Outputs SPDT With Independent Common
(Modicon PLC) Digital Outputs
2 Relay Outputs SPST With Same Common
(Modicon PLC) Analog Inputs
2 Analog Input NTC
(Modicon PLC) Analog Inputs
4 Configurable
(Modicon PLC) Digital Input Type
Sink Or Source
(Modicon PLC) Total Comm Ports
1
(Modicon PLC) Analog Input Type
Pt 1000 Temperature Probe
(Modicon PLC) Analog Input Type
NTC Temperature Probe
(Modicon PLC) Analog Outputs
5
(Modicon PLC) Analog Input Type
Impedance
(Modicon PLC) Comm Ports
1 CAN Port
Manufacturer
Schneider Electric
Component
Accessories
Sub Component
I/O Module
Features
This product is part of the Modicon M171/M172 range, an offer I/O modules for HVAC solutions
This additional I/O module offers 8 discrete inputs with sink or source (positive/negative) discrete input logic
It is a module with discrete input voltage ranges from 24V AC/DC to 48V DC and analogue output voltage ranges from 0V to 15V
This module offers 3 SPST relay output, 2 SPST relay output with same common and 2 SPDT relay output with independent common discrete output
It is an IP20 rated product
Its dimensions are 140mm (width) x 61.6mm (depth) x 110mm (height)
It weighs 0.19kg
The main application of this module is HVAC and pumping solution
Modicon M171/M172 benefits maximize profitability and energy efficiency by using scalable automation control with the Modicon M171/M172
Modicon M171/M172 logic controllers and intuitive software EcoStruxure Machine Expert - HVAC are designed for maximizing profitability and energy efficiency.
