Schneider Electric TM171ODM22R Modicon M171 Optimized Display 22 I/Os, Modbus
Normally In Stock
Code: 110891
Schneider TM5SAI4H Analog input module 4 current 0-20 mA differential, voltage +/- 10 V differential 15 bits + sign +/- 10 V, 15 bits 0-20 mA Motion controller, Logic controller 24 V DC -15-20 % White IP20IEC 61131-2 IP20 modular I/O-system Expansion modules "Slice" Analogue I/Os
Condition: New
CALL FOR LEAD TIME$264.55
Sale Price
$220.46
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Modicon M171 Optimized Display 22 I/Os, Modbus
Specifications
(Modicon PLC) Digital Inputs
6
(Modicon PLC) Analog Input Type
Current 0-20 Ma/4-20 Ma
(Modicon PLC) Analog Input Type
Voltage 0-10 V
(Modicon PLC) Analog Inputs
2 Configurable
(Modicon PLC) Analog Inputs
3 Analog Input NTC
(Modicon PLC) Analog Input Type
Voltage 0-1 V
(Modicon PLC) Analog Input Type
Voltage 0-5 V
(Modicon PLC) Digital Outputs
3 Relay Outputs SPST With Same Common
(Modicon PLC) Comm Ports
1 LAN Expansion Bus
(Modicon PLC) Digital Outputs
1 Open Collector
(Modicon PLC) Digital Outputs
2 Relay Outputs SPST With Independent Common
(Modicon PLC) Digital Input Type
Sink Or Source
(Modicon PLC) Total Comm Ports
2
(Modicon PLC) Comm Ports
1 RS485
(Modicon PLC) Analog Input Type
NTC Temperature Probe
(Modicon PLC) Analog Outputs
5
Manufacturer
Schneider Electric
Component
M171 Controller
(Modicon PLC) Total Analog Signals
For Simple & Compact Machines
Features
This product is part of the Modicon M171/M172 range, an offer of controllers for HVAC solutions
This controller offers 2 discrete inputs with sink or source (positive/negative) discrete input logic
The rated supply voltage ranges from 100V to 240V, ±10% AC
It is an IP20 rated product
Its dimensions are 74mm (width) x 76mm (depth) x 32mm (height)
It weighs 0.164kg
The main application of this module is HVAC and pumping solution
This product is certified by CE, CURus, CSA and EAC
It meets EN/IEC 60730 standard
It is suitable for DIN rail mount
Modicon M171/M172 benefits maximize profitability and energy efficiency by using scalable automation control with the Modicon M171/M172
Modicon M171/M172 logic controllers and intuitive software EcoStruxure Machine Expert - HVAC are designed for maximizing profitability and energy efficiency.
