Schneider Electric QOU390 QOU Miniature Circuit Breaker, 90A, 3P, 240V, 10kA
Normally In Stock
Code: 90734
Schneider QOU390 3P 90 A Standard Miniature circuit-breaker 120/240 VAC, 240 VAC, 120 VAC, 60 VDC 10 kA 120/240 VAC, 10 kA 240 VAC, 10 kA 120 VAC, 5 kA 60 VDC QOU 00900 - QOU BREAKERS & SWITCH 45 lbf.in (5.08 N.m AWG 12-AWG 2/0 4.45 in (113.03 mm 2.95 in (74.93 mm 2.25 in (57.15
Condition: New
CALL FOR LEAD TIME*NON-CANCELLABLE, NON-RETURNABLE*
$524.45
Sale Price
$437.04
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
QOU Miniature Circuit Breaker, 90A, 3P, 240V, 10kA
Specifications
Breaker Number of Poles
Three Pole
Breaker Voltage Rating
120 VAC
Breaker Voltage Rating
240 VAC
Breaker Voltage Rating
60 VDC
Component
Miniature Circuit Breaker
Manufacturer
Schneider Electric
Manufacturer
Square D
Line
QOU
Features
QOU miniature molded case circuit breakers are intended for use in residential and commercial applications
These circuit breakers are unit mount thermal magnetic circuit breakers
QOU breakers will automatically open a circuit under overload or short circuit conditions
They have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped
You can flush mount, surface mount or DIN rail mount these circuit breakers
This 3 pole QOU miniature circuit breaker is rated as 90 A at 240 VAC
This unit provides 10 kA breaking capacity
This breaker has lugs on both cable in and cable out connectors
They are tested and listed according to UL Standard 489 and CSA Standard C22.2 No
5 02 for circuit breakers
QOU circuit breakers are UL Listed under UL File E84967 DIVQ and are CSA Certified
These QOU breakers are packed in bulk.
