Code: 891756
Weiss NF4UGY2-200-4L Process Pressure Gauge
Normally In Stock
Weiss NF4UGY2-200-4L Process Pressure Gauge
Condition: New
Usually ships Same Day or Next DayMUST ORDER A MINIMUM OF $100 FROM WEISS FOR PRODUCT TO SHIP
$195.36
Sale Price
$162.80
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Weiss NF4UGY2-200-4L Process Pressure Gauge
Specifications
Manufacturer
Weiss Instruments
Component
Process Pressure Gauge
Features
SOCKET: AISI 316 stainless stee
BOURDON TUBE: AISI 316 S.S. - C tube to 600 psi. Coiled tube 1000 psi and above.
CONNECTING JOINTS: Welded MOVEMENT: Bushed stainless steel DIAL: White aluminum, black & red markings (psi & kPa)
POINTER: Black aluminum, micrometer adjustable CASE: Black reinforced thermoplastic fiberglass WINDOW: Acrylic
RING: Reinforced polypropylene GASKETS: Ethylene propylene ACCURACY: 0.5% ASME B40.1 Grade 2A
CONNECTIONS: 1/4" or 1/2" NPT lower or lower back CAT. NO. LF4UGY2: Lower connection only.
