Ideal for use in automotive and steel processing plants, pulp and paper processing plants, milk processing plants and creameries, fabrication yards and shipyards, refrigerated truck terminals and other industrial plant applications

WST Series is UL Listed and the WDS Series CSA Certified

Gasketed design allows use in raintight or watertight non-hazardous applications

Switch technology: operating mechanism designed to endure at least three times the number of operations required by NEMA and UL standards

Ergonomically designed handle is made of high-impact polymer or cast aluminum material for exceptional ruggedness, durability and corrosion resistance. WST has an insulated, dual-color polymer operating handle clearly indicates the switch being energized

Short circuit withstand rated to 200,000 RMS symmetrical amperes (Class R, J Fusing)

Class R fusing standard on fusible units. Product can be retrofitted with Class J, K, or S fusing

Stainless steel captive cover bolts for easy access and corrosion resistance. Stainless steel key-hole mounting feet for easy installation. Removable hinged cover for ease of installation and maintenance

Unit is equipped with defeatable door interlock which allows emergency access when switch is energized

Cover can be padlocked closed. Operating handle can be locked in the OFF position with provision to lock in ON position

Conduit entries are drilled and tapped to 1-1/2#8221

. Reducer bushings 1-1/2#8221

to 1-1/4#8221

and 1-1/2#8221

to 1#8221

provided at no extra charge

Not intended for use as a service disconnect (i.e., neutrals not available)
