Typical applications include pulp and paper mills, processing plants, chemical plants, petrochemical facilities, oil refineries, drilling rigs, foundries, waste and sewage treatment facilities, mining and steel mills

Compact, light weight, low profile design is suited for low mounting heights

Seven standard mounting hood designs allow for mounting in any location. Uses the same mounting hoods as the Mercmaster III HID. Retrofit adapters for Crouse-Hinds B, Mercmaster II, and Killark hoods available.

Customize to the application requirements with four different globe options: clear and diffused polycarbonate, clear glass, or prismatic glass refractor

Emergency version provides up to 1400 lumens illumination for 90 minutes of emergency lighting with clear lens or 800 lumens illumination for 180 minutes of emergency lighting and features functional diagnostic test self-initiates every 14 days after initial start up. A Duration test is automatically performed annually.

Hinge has high lip for added safety during installation and servicing. Hinge and bolt construction assures 360° compression at all points on fixture housing gasket for positive sealing. Swing away design of captive bolt and nut simplifies servicing

Watertight Pendant Hood with IP68 cord grip available to address water ingress into luminaire via conduit.

Mercmaster LED Low Profile offers a two-wire, 0-10V variable dimming input port for controlling the light output.

Mercmaster LED Low Profile is compatible with Emerson's Group Lighting Controls, allowing the control and monitoring of up to 10 luminaires with Mercmaster Connect LED integrated dimming controller and its daylight harvesting (adjustable output), motion sensing and scheduling capabilities to the group of luminaires.

Green and Red LEDs indicate charging status and provide fault warning on Emergency version

quick disconnect connector easily cuts power between LEDs and battery management module to allow maintenance in hazardous locations on Emergency version

Universal ratings provide vast regional coverage and can be specified by end users to meet NEC, CEC, IECEx or ATEX requirements
