Schneider Electric 9001KR9P35GH1 Harmony Chromium plated metal Mushroom Non-Illuminated Projecting 1 NO + 1 NC Modular
Normally In Stock
Code: 85837
Schneider XB4BS8444 trigger action and mechanical latching Emergency stop push-button, Emergency switching off push-button 2 NC Turn to release Chromium plated metal Round Red mushroom Ø 40 mm, unmarked Standard contacts 1 Harmony XB4 Standard 10 A EN/IEC 60947-5-1 1000000 cycles
Condition: New
Normally Stocked$127.36
Sale Price
$106.13
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Emergency stop switching off, metal, red mushroom, Ø40, Ø22, trigger latching turn to release, 2 NC
Specifications
(Switching-Indication) Illumination
Non-Illuminated
(Switching-Indication) Composition
Chromium Plated Metal
(Switching-Indication) Size
22 mm
(Switching-Indication) Shape
Round
(Switching-Indication) Amperage
6 Amp
(Switching-Indication) Profile
Standard
(Switching-Indication) Operation
Slow-Break
(Switching-Indication) Composition
Silver Alloy(Ag/Ni)
(Switching-Indication) Contacts Connection Type
Screw Clamp Terminals
(Switching-Indication) Color
Red
(Switching-Indication) UL Rating
UL 508
(Switching-Indication) Composition
Zamak
(Switching-Indication) IP Rating
IP 69
(Switching-Indication) IP Rating
IP 66
(Switching-Indication) Contact Configuration
2 NC
(Switching-Indication) Operation
Turn To Release
(Switching-Indication) Operation
Latching
(Switching-Indication) IP Rating
IP 67
(Switching-Indication) Operation
Trigger
(Switching-Indication) IP Rating
IP 69K
Manufacturer
Schneider Electric
Component
Modular Push Button
Features
Wide modular range to suit machines and operator safety.
Designed to fit in a 22mm cut-out or Harmony XAPK control station ensuring compatibility with pre-existing machinery.
Ergonomic design for emergency actuation in several environments
