Phoenix Contact 1487647 Safety relays PSR-UNI-L-2X2NO-2DO-24DC-SC
Normally In Stock
Code: 836969
Phoenix 1487647 Safety relays PSR-UNI-L-2X2NO-2DO-24DC-SC
Condition: New
Usually ships within 7-14 days. Call for ship time.*NON-CANCELLABLE, NON-RETURNABLE*
$392.82
Sale Price
$327.35
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1487647 This safety relay offers a range of configurable options including multi-functionality and SIL rating up to 3, compliant with Cat.4 and PL.e standards, and features two sensor circuits, one-half channel operation, automatic and manual start modes, monitored start, and two enabling current paths, accompanied by two signal outputs, operating on a US power supply of 24V DC and equipped with a plug-in screw terminal block.
Specifications
Safety Connection Method
Screw Connection
Safety Degree of Protection
IP20
Component
Safety Relay
Manufacturer
Phoenix Contact
Features
Up to Cat. 4/PL e in accordance with EN ISO 13849-1, SIL 3 in accordance with EN IEC 62061, SIL 3 in accordance with IEC 61508
2 independent circuits
Locally configurable
Configuration help via clipx ENGINEER dp
1- and 2-channel control
Manually monitored and automatic activation in a single device
Low housing width of only 22.5mm
