Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Schneider Electric XB5AA3341C0 red flush pushbutton white marked stop 1NC screw c cp gray
Normally In Stock
Code: 83371
Schneider XB5AA3341C0 spring return Push-button 1 NO Plastic colour plated gray Round White flush, up arrow black Standard contacts 1 Harmony XB5 Standard 10 A EN/IEC 60947-5-1 1000000 cycles AC-15, 2 A 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C, 1000000 cycles AC-15, 3 A 1
Condition: New
Usually ships Same Day or Next Day$29.98
Sale Price
$24.98
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
red flush pushbutton white marked stop 1NC screw c cp gray
Specifications
(Switching-Indication) Operation
Spring Return
(Switching-Indication) Color
Black
(Switching-Indication) Color
White
(Switching-Indication) Contact Configuration
1 NO
(Switching-Indication) Size
22 mm
(Switching-Indication) Shape
Round
(Switching-Indication) Amperage
6 Amp
(Switching-Indication) Profile
Standard
(Switching-Indication) Operation
Slow-Break
(Switching-Indication) Composition
Plastic
(Switching-Indication) Composition
Silver Alloy(Ag/Ni)
(Switching-Indication) Contacts Connection Type
Screw Clamp Terminals
(Switching-Indication) UL Rating
UL 508
(Switching-Indication) IP Rating
IP 66
(Switching-Indication) IP Rating
IP 67
Manufacturer
Schneider Electric
Component
Modular Push Button
Features
This push-button provides a simple and robust control to machines and processes
It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections
Its schematic is clearly visible at a distance thanks to clear colors and markings, minimizing errors during initial wiring and later maintenance operations.

Code: 83371
Schneider Electric XB5AA3341C0 red flush pushbutton white marked stop 1NC screw c cp gray
$29.98
Sale Price
$24.98
