Schneider Electric XB5FA42 Push button flush mounted, plastic, red, 30 mm, spring return, unmarked, 1NC
Normally In Stock
Code: 83269
Schneider XB5FA42 spring return Push-button 1 NC ZBYF2101, ZBYF4101, ZBYF6101, ZBYF6102, ZBZF32, ZBZF33, ZB4FBZ007 Plastic, Dark gray plastic Round Red flush, unmarked Standard contacts 1 Harmony XB5 Built-in-flush 10 A EN/IEC 60947-5-1 1000000 cycles AC-15, 2 A 230 V 3600 cyc/h
Condition: New
Usually ships Same Day or Next Day$44.99
Sale Price
$37.49
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Push button flush mounted, plastic, red, Ø30, spring return, unmarked, 1NC
Specifications
(Switching-Indication) Size
30 mm
(Switching-Indication) Operation
Spring Return
(Switching-Indication) Shape
Round
(Switching-Indication) Amperage
6 Amp
(Switching-Indication) Profile
Flush
(Switching-Indication) Operation
Slow-Break
(Switching-Indication) Composition
Plastic
(Switching-Indication) Composition
Silver Alloy(Ag/Ni)
(Switching-Indication) Contacts Connection Type
Screw Clamp Terminals
(Switching-Indication) Color
Red
(Switching-Indication) UL Rating
UL 508
(Switching-Indication) IP Rating
IP 69
(Switching-Indication) IP Rating
IP 66
(Switching-Indication) Contact Configuration
1 NC
(Switching-Indication) IP Rating
IP 67
(Switching-Indication) IP Rating
IP 69K
Manufacturer
Schneider Electric
Component
Modular Push Button
Features
Quick and easy assembly and disassembly
Robustness to withstand harsh environments
With various types of connection: screw clamp, connector, Faston connector, spring terminal, or printed circuit board
