Accuracy± 0.05 %

Accuracy Detail ≤ ±0.05% of span

ADC Resolution 22 bit

Additional Features 1 HART Protocol Revisions: HART 7 and HART 5

Approvals "ATEX 2014/34/EU: KEMA 03ATEX1537 IECEx: KEM 10.0083X FM: FM17US0013X CSA: 1125003 INMETRO:NCC 12.0844 X EAC Ex TR-CU 012/2011: RU C-DK.GB08.V.00410 DNV-GL Marine: Stand. f. Certific. No. 2.4 SIL: Hardware assessed for use in SIL applications Authority Requirements: EMC: 2014/30/EU EAC: TR-CU 020/2011 "

Cable Resistance 5 Ω

Calibration Temperature, Max 28 °C

Calibration Temperature, Min 20 °C

Cold Junction Compensation Constant, internal or external via a Pt100 or Ni100 sensor

DAC Resolution 16 bit

Diameter 44 mm

Drop 8 Vdc

Electrical Connection Screw Terminal

Electrical Output 4 to 20 mA

EMC Standard NAMUR NE 21

Enclosure Ratings IP00, IP68

Height 20.2 mm

Humidity Range Up to 95% non-condensing

Input Control Signal -800 to 800 mV

Input Resistance 10 MΩ

Input Type Thermocouple, RTD, Resistance, Voltage

Isolation 1.5 kVAC / 50 VAC

Offset 50% of selected max. value

Operating Temperature, Max 85 °C

Operating Temperature, Min -40 °C

Output Detail Min. Signal Range: 16 mA NAMUR NE43 Upscale/Downscale: 23 mA/3.5 mA

Output Load  ≤ (Vsupply - 8)/0.023 Ω

Probe Length 0 mm

Programmable Functions Loop Link and HART

Response Time 1 to 60 sec

RTD Type Pt50,Pt100,Pt200,Pt500,Pt1000,Ni50,Pt100,Pt120,Pt1000

Sensor Break Detection  3.5 to 23 mA

Sensor Current 0.2 mA

Sheath Material N/A

Signal/Noise Ratio > 60 dB

Supply Power Type DC

Supply Voltage 8 to 30 Vdc

Temperature Coefficient ≤ ±0.005%/°C

Temperature Input Range N/A

Thermocouple Type B, E, J, K, L, N, R, S, T, U, W3, W5, LR

Update Rate, Max 440 ms

Vibration IEC 60068-2-6

2 to 25 Hz: ±1.6 mm

25 to 100 Hz: ±4 g

Weight 50 g

Wiring/Connector Table 2-, 3-, or 4-Wire
