Code: 817323
Omega HKMQSS-125U-8 Thermocouple Probe Assembly
Normally In Stock
Omega HKMQSS-125U-8 Thermocouple Probe Assembly
Condition: New
Usually ships Same Day or Next Day$92.18
Sale Price
$76.82
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Thermocouple Probe Assembly, Quick Disconnect, High Temp Miniature CONN, K Type, 0 °C to 1070 °C, 0.125 " x 8 " (DxL) Probe, 304 SS, Immersion, Ungrounded, ANSI, HKMQSS Series, Each
Specifications
Manufacturer
Omega Engineering
(Instrument-Sensor) Type
Thermocouple
(Instrument-Sensor) Temperature Range
0 °C - 900 °C
Component
Thermocouple Probe Assembly
Features
Connector Body Temperature Ratings: With Ferrite Cores: 120°C (248°F) Without Ferrite Cores: 260°C (500°F)
Environmentally Friendly Cadmium-Free Liquid Crystal Polymer
Miniature Probes with Sheath Diameters from .010 to .125 inch
6 and 12 inch Lengths
Cable ClampPCLM
Electrical ConnectionCeramic Miniature Male Thermocouple Connector
Mating ConnectorCeramic Miniature Female Thermocouple Connector
Process Connection SizeN/A
Process Temperature, Min0 °C
Safety ClipSMCL
Temperature Sensor TypeThermocouple
