Omega CL541-PLUS Handheld Calibrator
Normally In Stock
Omega CL541-PLUS Handheld Calibrator
Condition: New
Usually ships Same Day or Next Day$2867.69
Sale Price
$2389.74
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Thermocouple Calibrator, Automated, ± (0.008 % of Rdg + 0.006 mV) Accuracy, Supports K, J, E, T Types, 50 hours, Read & Source Signals, CL541-PLUS Series, Each
Specifications
Manufacturer
Omega Engineering
Component
Handheld Calibrator
Features
Source and Read 4 T/C Types J, K, T AND E Plus mV
Easy-to-Read Backlight Display
Easily Change T/C Types and Scale
Calibrate Quickly With Automatic Output Stepping
Accuracy± 0.008 %
Accuracy Detail± (0.008% of Reading + 0.006 mV)
Additional Features 1Read & Source Signals
Battery IndicationA low battery indication is displayed when the battery voltage drops below the operating level
Battery life50 hr
Cold Junction Compensation± 0.1°F
Display TypeLCD
Display Type NoteHigh contrast graphic liquid crystal display, LED backlighting for use in low lit areas
Height40.64 mm
Length143 mm
Operating Temperature, Min-25 °C
Over-Voltage ProtectionOver-voltage protection to 60 Vdc (rated for 30 seconds)
Relative Humidity, Max0.9
Relative Humidity, Min10%
Relative Humidity Note10% ≤RH ≤90% (0 to 35°C), non-condensing
10% ≤RH ≤70% (35 to 60°C), non-condensing
Supply Voltage6 Vdc
Thermocouple TypeJ, K, T, E
Voltage ReadInput Impedance: >10 MΩ
Open Thermocouple
Threshold: 10,000 Ω nominal
Pulse: <10 microamp pulse for 300 milliseconds
Normal Mode Rejection: 50/60 Hz, 50 dB
Common Mode Rejection: 50/60 Hz, 120 dB
Voltage SourceOutput Impedance: < 0.3 Ω
Source Current: > 20 mA (drives 80 mV into 10 Ω)
Noise: ≤4 microvolts p-p for frequencies of 10 Hz or below
Weight12.1 oz
Weight Note12.1 oz (including boot and batteries)
Width76.2 mm
