Omega D6300 7 CH DIF TC INPUT MODULE CE
Normally In Stock
Code: 790152
Omega D6300 7 CH DIF TC INPUT MODULE CE
Condition: New
Usually ships Same Day or Next Day$781.72
Sale Price
$651.43
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Serial Interface Module, TC I/P, 25/s Sample Rate, 16 °C, 7 Inputs, RS-485, DC Power, Modbus RTU, D6000 Series, Each
Specifications
Manufacturer
Omega Engineering
Conditioner Supply Voltage
10-30 Vdc
Component
Serial Interface Module
Features
Complete Data Acquisition Systems
Analog and Digital I/O Models Available
RS485 Serial Communications Interface
MODBUS® RTU Protocol
Baud Rate9600 to 115200
Common Mode VoltageInput to Output at 115 Vrms, 60 Hz: 500 Vrms
Data InterfaceRS485
Data Interface NoteModbus RTU protocol
Configuration Method: Modbus
Digital FilterProgrammable
Digital Output5 mA minimum, 10 mA maximum
Electrical ConnectionScrew Terminal
Height102 mm
Length38 mm
MaterialsABS
MemoryEEPROM
Mounting Note165 mm on center
Operating Temperature, Max70 °C
Operating Temperature, Min-25 °C
Output Settling Time0.1% FS: 1 ms
Relative Humidity0 to 95% RH non-condensing
Storage Temperature, Max85 °C
Storage Temperature, Min-25 °C
Supply Power TypeDC
Supply Voltage10 to 30 Vdc
Transmission Distance1219 m
Width152 mm
