Omega FT01160000 THERMOSTAT,NC,15C,OP.41F CLOSE
Normally In Stock
Code: 777124
Omega FT01160000 THERMOSTAT,NC,15C,OP.41F CLOSE
Condition: New
Usually ships Same Day or Next Day$34.45
Sale Price
$28.71
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Tamperproof Thermostat, Heat Control, 5 °C, AC Supply, N.C, Fixed Temperature, DIN Rail Mount, FT011 Series, Each
Specifications
Component
Thermostat
Manufacturer
Omega Engineering
Features
Fixed Setpoint
Compact Design
Color Coded Modules
DIN Rail Mountable
Status Controlfalse
Contact TypeN/A
Current Rating10 A
Electrical Connection Note2-Pole terminal for AWG 14 max [2.5 mm² (0.1 in²)] 4-pole terminal for dual model AWG 14
EMCEN50022
Enclosure RatingsIP20, NEMA Type 2
Form factorClip for 35 mm DIN Rail
Height47 mm
Length22 mm
Number of CircuitsN/A
Operating Current20 mA
Operating Temperature, Max70 °C
Operating Temperature, Min-40 °C
Service Life>100,000 cycles
5 A resistive/1.6 A inductive @ 240 Vac
DC 30 W
Storage Temperature, Max80 °C
Storage Temperature, Min-45 °C
Supply VoltageN/A
Temperature RangeFixed
Tolerance±5.4°F
Width33 mm
