Phoenix Contact 1066718 DC/DC converter QUINT4-PS/12-24DC/24DC/2.5/SC
Normally In Stock
Code: 738306
Phoenix Contact QUINT4-PS/12-24DC/24DC/2.5/SC - QUINT, DC/DC converter, 12 VDC - 24 VDC, IP20 - 1066718
Condition: New
Usually ships Same Day or Next Day$225.72
Sale Price
$188.10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1066718 A DC-DC converter with primary switching, the QUINT POWER, can be mounted on a DIN rail and accepts an input voltage between 12V and 24V DC. It provides a constant output of 24V DC at a maximum current rating of 2.5A.
Specifications
Manufacturer
Phoenix Contact
Power Supply Voltage Input Range
12 VDC - 24 VDC
Component
DC-DC
Features
Most powerful output side: easy system expansion, reliable heavy load startup and miniature circuit breaker tripping
Most comprehensive signaling: preventive function monitoring reports critical operating states before errors occur
Free selection between Push-in and screw connection
Downloads
083210725_04_DNVShip_TAA00000BV.pdf083219678_00_ULListHazlocCAUS_FILEE199827.pdf083219690_00_ULListCAUS_FILEE123528.pdf097138542_00_DoC_UK.pdf097730422_00_MDoC_G3_de_en.pdf1066718_01_Product Environmental Footprint.pdfchina rohs declaration-spreadsheet.pdfchina rohs declaration-spreadsheet.stpChina RoHS Declaration_1066718_01_en.pdfChina RoHS Declaration_1066718_01_zh.pdfcoc document.pdfeu declaration of conformity.pdfmanufacturer's declaration for noxious gas test.pdfPhoenix Data Sheet.pdfproduct drawing.dxfproduct drawing.pdfpxc_1066718_01_00_QUINT4-PS-12-24DC-24DC-2-5-SC_2D.dxf.crdownloadsimplified 3d model of the item.pdfsimplified 3d model of the item.stpSpecification Sheet.pdfuk declaration of conformity.pdf
