Phoenix Contact 2904957 Safety relays PSR-MS55-1NO-1DO-24DC-SC
Normally In Stock
Code: 72915
Phoenix 2904957 Safety relays
Condition: New
Usually ships within 7-14 days. Call for ship time.$185.95
Sale Price
$154.96
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2904957 This safety relay is designed to monitor non-equivalent signal generators and can operate up to SIL 3, Cat 4, PL e, in a two-channel configuration. It features manual start functionality with monitored start, single enabling current path, and accepts input voltages of 24V DC from the US terminal block, which is secured using fixed screw terminals.
Specifications
Safety Connection Method
Screw Connection
Safety Degree of Protection
IP20
Safety Contact Type
1 Enabling Current Path
Component
Safety Relay
Manufacturer
Phoenix Contact
Safety Relay Safety Level
SIL Cat 4
Safety Relay Supply Voltage
24 Volt
Features
1 enabling current path, 1 digital signal output
Low housing width of just 6.8 mm
Two-channel non-equivalent control
Up to Cat. 4/PL e in accordance with EN ISO 13849-1, SIL 3 in accordance with EN IEC 62061
Manual and monitored activation
