Code: 722681
Phoenix Contact 1788761 DIN rail connector MSTBVK 2,5/ 6-G-5,08
Normally In Stock
Phoenix Contact MSTBVK 2,5/ 6-G-5,08 - DIN rail connector, 6 Positions, 5.08 mm, 320 VAC, 12 Amp, Cu alloy - 1788761
Condition: New
Usually ships Same Day or Next Day$28.45
Sale Price
$23.71
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1788761 A DIN rail connector has a nominal cross-sectional area of 2.5 mm² and is colored green, with a maximum current rating of 12 A and a rated voltage of 320 V, utilizing tin contact surfaces and features six pin connections on a single row with a pitch of 5.08 mm, requiring screw connection with a tension sleeve for secure attachment and featuring an L-slotted screw head, allowing for conductor to PCB connection at 0° angle, with a plug-in system designed as COMBICON MSTB 2,5, and does not have a locking mechanism, neither mounted nor packaged in cardboard.
Specifications
Connector Amperage
12 Amp
Connector Color
Green
Connector Material
Cu Alloy
Component
DIN Rail Connector
Manufacturer
Phoenix Contact
Number of Connections
6
Number of Positions
6
Connector Pitch
5.08 mm
Features
Direct plug-in block for mounting on NS 15 DIN rail
Can be combined with the MSTB 2,5 range
Well-known connection principle allows worldwide use
