Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 722680
Phoenix Contact 1787966 DIN rail connector UMSTBVK 2,5/ 6-GF-5,08
Normally In Stock
Phoenix Contact UMSTBVK 2,5/ 6-GF-5,08 - DIN rail connector, 6 Positions, 5.08 mm, 320 VAC, 12 Amp, Cu alloy - 1787966
Condition: New
Usually ships Same Day or Next Day$26.11
Sale Price
$21.76
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1787966 The DIN rail connector has a nominal cross-sectional area of 2.5mm², green color, and is rated for 12A of current at 320V. It features a Sn contact surface with a pin connection type and six potentials. The connector is 5.08mm in pitch, connects via screw attachment with tension sleeve, and has a standard Pin connector pattern alignment. When connected, the connector uses a lock mechanism secured by a L Slotted screw head and can be mounted using a threaded flange, packaged in cardboard.
Specifications
Connector Amperage
12 Amp
Connector Color
Green
Connector Material
Cu Alloy
Component
DIN Rail Connector
Manufacturer
Phoenix Contact
Number of Connections
6
Number of Positions
6
Connector Pitch
5.08 mm
Features
Direct plug-in block with universal foot for mounting on NS 32 or NS 35 DIN rail
Can be combined with the MSTB 2,5 range
Screwable flange for superior mechanical stability
Well-known connection principle allows worldwide use
