Phoenix Contact 1642182 Conductor connector Q 1,5/4IDC/24-24KU-KU BK PE
Normally In Stock
Code: 722539
Phoenix Contact Q 1,5/4IDC/24-24KU-KU BK PE - Conductor connector, 4 Positions, 500 VAC, 15 Amp - 1642182
Condition: New
Usually ships Same Day or Next Day$19.81
Sale Price
$16.51
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1642182 The QUICKON cable connector is available in a black colour with a rating suitable for cables with cross-sectional areas ranging from 0.75 to 1.5 mm2, and is designed to operate at voltages up to 500 V and currents up to 15 A. It can be used for cables with diameters of either 6 mm or 12 mm in diameter.
Specifications
Connector Color
Green
Connector Amperage
15 Amp
Component
Connector
Manufacturer
Phoenix Contact
Number of Connections
4
Number of Positions
4
Features
Innovative and time saving - QUICKON fast connection for time saving of up to 80 % for on-site connection
Robust throughout: housing with IP65/IP67 protection for a wide range of applications
Safer connection with mechanical coding to protect against mismatching, and touch-proof protection in accordance with DIN EN 0105
Easy and safe - with the cable connector, you can repair or extend cables quickly, in combination with the connector as well as the coupling connection
