Code: 722530
Phoenix Contact 1787940 DIN rail connector UMSTBVK 2,5/ 4-GF-5,08
Normally In Stock
Phoenix Contact UMSTBVK 2,5/ 4-GF-5,08 - DIN rail connector, 4 Positions, 5.08 mm, 320 VAC, 12 Amp, Cu alloy - 1787940
Condition: New
Usually ships Same Day or Next Day$18.95
Sale Price
$15.79
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1787940 A DIN rail connector with a nominal cross section of 2.5mm² features four pins for connecting multiple potentials, has a pitch of 5.08mm and is designed to accommodate up to 12A of current while rated for 320V. It comes in a green color, uses Sn contacts and employs a screw connection method with a tension sleeve, allowing for secure mounting via its threaded flange design packaged in cardboard.
Specifications
Connector Amperage
12 Amp
Connector Color
Green
Connector Material
Cu Alloy
Component
DIN Rail Connector
Manufacturer
Phoenix Contact
Number of Connections
4
Number of Positions
4
Connector Pitch
5.08 mm
Features
Direct plug-in block with universal foot for mounting on NS 32 or NS 35 DIN rail
Can be combined with the MSTB 2,5 range
Screwable flange for superior mechanical stability
Well-known connection principle allows worldwide use
