Code: 722519
Phoenix Contact 1716519 Feed-through plug DFK-PC 5/ 3-ST-7,62
Normally In Stock
Phoenix Contact DFK-PC 5/ 3-ST-7,62 - Feed-through plug, 3 Positions, 7.62 mm, 1000 VAC, 32 Amp, Cu alloy - 1716519
Condition: New
Usually ships Same Day or Next Day$10.28
Sale Price
$8.57
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1716519 The feed-through connector features a nominal cross-sectional area of 6 mm² and has three potentials. It is rated for 32 A at 1000 V (III/2) voltage. The contact surface is made of tin and the connection type is pin-based. There are no rows, positions, or connections specified. This product falls within the DFK-PC 5/..-ST range, has a pitch of 7.62 mm, and utilizes a screw connection with tension sleeve.
Specifications
Connector Color
Green
Connector Amperage
32 Amp
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Number of Connections
3
Number of Positions
3
Connector Pitch
7.62 mm
Component
Feed-Through Plug
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
Flange system enables secure fixing to the housing panel by means of tool-free snap-in locking or screws
