Phoenix Contact 2906282 Lightning/surge arrester type 1/2 VAL-MS-T1/T2 48/12.5/O-FM
Normally In Stock
Code: 72141
Phoenix 2906282 Arrester combination -48 VDC Screw connection Lightning/surge arrester type 1/2 Surge Protection
Condition: New
Usually ships Same Day or Next Day$218.52
Sale Price
$182.10
MUST BUY IN PACKS OF 12
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2906282 A universal varistor-based plug-in lightning/surge arrester is designed specifically for single-phase power supply networks that utilize a two-conductor system consisting of the live line (L1) and the neutral and earth (N and PE). This device features common connections between these conductors, including an N connection to one conductor and a PE connection to the other. Additionally, this plug-in arrester is equipped with remote indication contacts that allow for easy monitoring and diagnosis of its performance.
Specifications
Fault Warning
None
Arrester Class according to IEC
C1
Arrester Class according to IEC
C3
Direction of Action
Line-Earth Ground
Manufacturer
Phoenix Contact
Nominal Discharge Current
350 Amp
Connection Method
Screw Connection
Surge Protector Type
Interference Filters
Maximum Continous Voltage
38 Volt
Surge Protector Line Voltage
-48 Volt
Component
Surge Arrester
Features
Coding when protective plug is inserted for the first time
Plug-in direction parallel to the conductor axis
DIN rail mounting
Rack-mount 2U panel applications
Accepts Type 1 and Type 2 VAL-MS plugs
Versions with and without floating remote indication contact
Downloads
Phoenix 2906282 CAD data International.dxfPhoenix 2906282 CAD data International.pdfPhoenix 2906282 CAD data International.stpPhoenix 2906282 Flyer English.pdfPhoenix 2906282 Manufacturers declaration English.pdfPhoenix 2906282 Manufacturers declaration International.pdfPhoenix 2906282 Package Slip International.pdfPhoenix 2906282 Software International.zipPhoenix 2906282 Surge Protection English.pdfPhoenix 2906282 Tender Text English.zip
