PT-IQ-2X2-24DC-P Phoenix Contact 2800804 Replacement plug Surge protection plug
PT-IQ-2X2-24DC-P Phoenix 2800804 Replacement plug 24 VDC pluggable Surge protection plug Surge Protection
Normally In Stock! Order now!
Condition: New
Usually ships within 7-14 days. Call for ship time.
Price: $386.25
Sale Price:
$321.36
Surge protection plug with integrated multi-stage status indicator on the module for two 2-wire floating signal circuits. 24 VDC nominal voltage.
| Specifications | |
| Fault Warning | Optical |
| Arrester Class according to IEC | II |
| Arrester Class according to IEC | T2 |
| Max Discharge Capacity | 100 A (264 V AC) |
| Manufacturer | Phoenix Contact |
| Connection Method | Screw connection |
| Surge Protector Line Voltage | 24 Volt |
| Surge Protector Type | Replacement plug |
| Maximum Continous Voltage | 264 Volt |
| Nominal Discharge Current | 20 kA |
- Maximum ease of maintenance, thanks to the 2-piece design
- Integration of the status message into the system controller via group remote signaling
- The signal is not influenced during maintenance work, thanks to the impedance-neutral insertion and removal of protective plugs
- Predictive monitoring with 3-stage LED display
- Maximum protection for MCR applications with high discharge capacity
Customer Reviews
0.0
All Reviews
Phoenix 2800804 CAD data International.dxf
Phoenix 2800804 CAD data International.pdf
Phoenix 2800804 CAD data International.stp
Phoenix 2800804 Flyer English.pdf
Phoenix 2800804 Flyer English-2.pdf
Phoenix 2800804 Manufacturers declaration English.pdf
Phoenix 2800804 Manufacturers declaration International.pdf
Phoenix 2800804 Package Slip International.pdf
Phoenix 2800804 Software International.zip
Phoenix 2800804 Surge Protection English.pdf
Phoenix 2800804 Tender Text English.zip
