Code: 71916
Phoenix Contact 2800623 Type 2 surge protection plug VAL-MS 600DC-PV-ST
Normally In Stock
VAL-MS 600DC-PV-ST Phoenix 2800623 Replacement plug 800 VDC pluggable Type 2 surge protection plug Surge Protection
Condition: New
Usually ships Same Day or Next Day$132.30
Sale Price
$110.25
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2800623 Replacement plug options for combining multiple photovoltaic (PV) arresters from the VAL-MS 600DC-PV series are available within the product range.
Specifications
Max Discharge Capacity
80 A
Fault Warning
Optical
Arrester Class according to IEC
II
Arrester Class according to IEC
T2
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Maximum Continous Voltage
260 Volt
Surge Protector Type
Surge Arrester
Nominal Discharge Current
20 Ka
Surge Protector Line Voltage
800 Volt
Component
Surge Protection Plug
Features
Optimum capabilities for photovoltaic systems of up to 1,500 V DC
Independently tested safety through KEMA approval
High operational safety with a short-circuit current rating of up to 2,000 A
Can be used at altitudes of up to 6,000 m in accordance with EN 50539-11
Downloads
Phoenix 2800623 CAD data International.dxfPhoenix 2800623 CAD data International.pdfPhoenix 2800623 CAD data International.stpPhoenix 2800623 Flyer English.pdfPhoenix 2800623 Manufacturers declaration English.pdfPhoenix 2800623 Manufacturers declaration International.pdfPhoenix 2800623 Package Slip International.pdfPhoenix 2800623 Software International.zipPhoenix 2800623 Surge Protection English.pdfPhoenix 2800623 Tender Text English.zip
