Phoenix Contact 2910379 Type 1 surge protection device VAL-US-277/80/3+1V-FM
Normally In Stock
Code: 71858
VAL-US-277/80/3+1V-FM Phoenix 2910379 Surge arrester 240/415 VAC Plug-in/screw connection via COMBICON,Screw connection,Fork-type cable lug Type 1 surge protection device Surge Protection
Condition: New
Usually ships Same Day or Next Day$776.39
Sale Price
$646.99
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2910379 A four-channel surge protective device with a remote indicator contact is available for installations that require AC power, specifically at 277/480 volts and with an additional ground wire.
Specifications
Manufacturer
Phoenix Contact
Surge Protector Line Voltage
240-415 Volt
Component
Surge Protection Device
Features
Multi-channel type 2 protective devices
UL open terminal listed SPD
Optical, mechanical status indication for the individual arresters
With floating remote indication contact
Mechanical coding of all slots
Plugs can be checked with CHECKMASTER
Disconnect device on each individual plug
Secure hold of plugs in the event of high lightning current loads and strong vibrations thanks to new latching
Downloads
Phoenix 2910379 CAD data International.dxfPhoenix 2910379 CAD data International.pdfPhoenix 2910379 CAD data International.stpPhoenix 2910379 Flyer English.pdfPhoenix 2910379 Manufacturers declaration International.pdfPhoenix 2910379 Package Slip International.pdfPhoenix 2910379 Surge Protection English.pdfPhoenix 2910379 Tender Text English.zip
