Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 2910369 Type 1 surge protection device VAL-US-240D/40/2+0-FM
Normally In Stock
Code: 71827
VAL-US-240D/40/2+0-FM Phoenix 2910369 Surge arrester 240 VAC Plug-in/screw connection via COMBICON,Screw connection,Fork-type cable lug Type 1 surge protection device Surge Protection
Condition: New
Usually ships Same Day or Next Day$299.65
Sale Price
$249.71
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2910369 A surge protective device designed to protect against voltage spikes on a 240V AC system that is corner grounded and operates in delta configuration, features two separate channels and includes an optional remote indicator contact.
Specifications
Fault Warning
Optical
Combined Surge
6 Kv
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Maximum Continous Voltage
264 Volt
Nominal Discharge Current
3 Ka
Surge Protector Line Voltage
240 Volt
Component
Surge Protection Device
Features
Easy integration into existing applications with UL Open Type 1 Listed
Available for all standard network configurations in accordance with NEMA
Available, useable, and mountable Europe-wide with the CE marking
Easy monitoring of system status with a local status indicator and remote indication contact
Plugs can be tested with CHECKMASTER 2
Downloads
Phoenix 2910369 CAD data International.dxfPhoenix 2910369 CAD data International.pdfPhoenix 2910369 CAD data International.stpPhoenix 2910369 Flyer English.pdfPhoenix 2910369 Manufacturers declaration International.pdfPhoenix 2910369 Package Slip International.pdfPhoenix 2910369 Surge Protection English.pdfPhoenix 2910369 Tender Text English.zip
