Phoenix Contact 2800976 Surge protection device PT-IQ-1X2-24DC-UT
Normally In Stock
Code: 71698
PT-IQ-1X2-24DC-UT Phoenix 2800976 Surge protection for measurement and control technology 24 VDC Screw connection,DIN rail NS35 Surge protection device Surge Protection
Condition: New
Usually ships within 7-14 days. Call for ship time.$253.84
Sale Price
$211.53
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2800976 A surge protection system is available that consists of a protective plug and a base element, both connected to an integrated multi-stage status indicator, designed specifically for use with 2-wire floating signal circuits that are compatible with HART protocols, making it suitable for application in safety-related systems where SIL 3 certification is required.
Specifications
Fault Warning
Optical
Max Discharge Capacity
50 A
Arrester Class according to IEC
PV I - II
Arrester Class according to IEC
PV T1 - T2
Impulse Discharge Current
6.25 Ka
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Line Voltage
24 Volt
Surge Protector Type
PV Arrester
Nominal Discharge Current
20 Ka
Component
Surge Protection Device
Features
Maximum ease of maintenance, thanks to the 2-piece design
Integration of the status message into the system controller via group remote signaling
Install quickly and error-free with DIN rail connectors
Predictive monitoring with 3-stage LED display
Maximum protection for MCR applications with high discharge capacity
Downloads
Phoenix 2800976 CAD data International.dxfPhoenix 2800976 CAD data International.pdfPhoenix 2800976 CAD data International.stpPhoenix 2800976 Flyer English-2.pdfPhoenix 2800976 Flyer English.pdfPhoenix 2800976 Manufacturers declaration English.pdfPhoenix 2800976 Manufacturers declaration International.pdfPhoenix 2800976 Package Slip International.pdfPhoenix 2800976 Product Information English.pdfPhoenix 2800976 Software International.zipPhoenix 2800976 Surge Protection English.pdfPhoenix 2800976 Tender Text English.zip
