Phoenix Contact 2861852 Function module IB IL CNT-PAC
Normally In Stock
Code: 71236
IB IL CNT-PAC Phoenix 2861852 I/O component Inline Input,Output,Terminal Inline local bus 500 kbps Inline data jumper,Spring-cage connection PLC & IO
Condition: New
Usually ships within 7-14 days. Call for ship time.$568.73
Sale Price
$473.94
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2861852 The inline counter terminal is a comprehensive device equipped with essential components including a connector and marking fields, one counter input port, one control input port, an output port, a power supply of 24 V DC, a maximum current draw of 500 mA, and utilizes a three-conductor connection system.
Specifications
PLC & IO Network Interface
Inline Local Bus
PLC & IO Transmission Speed
500 Kbps
PLC & IO Degree of Protection
IP20
PLC & IO Connection Method
Inline Data Jumper
PLC & IO Connection Method
Spring-Cage Connection
PLC & IO Type
Inline
Manufacturer
Phoenix Contact
PLC & IO Number of Counter Inputs
1
Component
I/O Component
Features
Four operating modes: event counting, time or state-controlled frequency measurement, time measurement (period or pulse length), and pulse generator
1 control input
1 freely parameterizable switching output
1 counter input
Processing of 5 V or 24 V signals
Input frequency of up to 100 kHz
16-bit counter value for time measurement
24-bit counter value for event counting and frequency measurement
Downloads
Phoenix 2861852 Application Note English-2.pdfPhoenix 2861852 Application Note English.pdfPhoenix 2861852 CAD data International.dxfPhoenix 2861852 CAD data International.pdfPhoenix 2861852 CAD data International.stpPhoenix 2861852 Configuration software International.zipPhoenix 2861852 Data Sheet English.pdfPhoenix 2861852 EPLAN Macro International.z13Phoenix 2861852 EPLAN Macro International.zipPhoenix 2861852 Function Module International.msiPhoenix 2861852 Function Module International.zipPhoenix 2861852 Manual English-2.pdfPhoenix 2861852 Manual English.pdfPhoenix 2861852 Manufacturers declaration International-2.pdfPhoenix 2861852 Manufacturers declaration International.pdfPhoenix 2861852 Package Slip International.pdfPhoenix 2861852 Tender Text English.zipPhoenix 2861852 Various English.pdf
