Schneider Electric SER8350A0B11 - Line-Voltage Fan Coil Room Controller: BACnet MS/TP, RH sensor & control, White Case/Fascia
Normally In Stock
Code: 696423
Schneider Electric SER8350A0B11 - Line-Voltage Fan Coil Room Controller: BACnet MS/TP, RH sensor & control, White Case/Fascia
Condition: New
Usually ships Same Day or Next Day$480.77
Sale Price
$400.64
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric SER8350A0B11 - Line-Voltage Fan Coil Room Controller: BACnet MS/TP, RH sensor & control, White Case/Fascia
Specifications
Manufacturer
Schneider Electric
Component
Room Controller
Features
SER8300 Series room controllers are used for Line Voltage Fan Coil Unit control
The room controllers rated supply voltage is 7V DC at 2.4watts
The room controller is colored white and is equiped with a communication port that uses BACnet MS/TP protocol
Its Room and Outdoor Air Temperature Display Range is between -40 and 50 oC
The measurement accuracy is +/- 0.5%
The temperature setting range is 12 to 37.5oC for cooling and 4.5 to 32 oC for heating
The room controller is equiped with 3 digital inputs
The product follows the following standards: IEC 61326-1: 2005, FCC part 15 subpart C, RSS 210 issue 8, FCC part 15 subpart B,,ICES-003, EN 60950-1: 2006/A2, EN 60950-1: 2013, ETSI EN 301 489-1: v1.9.2
The product follows the directives: 2014/30/EU - electromagnetic compatibility, 2014/35/EU - low voltage directive, 2014/53/EU - radio equipment directive
The ambient air temperature for operation is between 0 and 50oC
The relative humidity for operating or storage is between 0 and 75% non condensing
The humidity reading range is 10 to 90% RH non-condensing.
