Phoenix Contact 2900359 Solid-state relay module PLC-OPT-120UC/ 48DC/100/SEN
Normally In Stock
Code: 68644
Phoenix 2900359 Solid-state relay module 120 VAC (110 VDC) Push-in connection Input Function,Output Function Relays
Condition: New
Usually ships Same Day or Next Day $38.15
Sale Price
$31.79
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2900359 A PLC-Interface for input functions features a PLC-BPT.../SEN basic terminal block with push-in connection and plug-in miniature solid-state relay. This interface is designed to be mounted on DIN rail NS 35/7,5, allowing for flexible installation options. The input features one N/O contact, accepting power from both 120 V AC and 110 V DC sources. The output can produce a range of voltage levels from 3-48 V DC while maintaining a maximum current draw of 100 mA.
Specifications
Relay Mounting
Din Rail
Relay Connection Type
Push-In Connection
Component
Relay Module-Solid State
Manufacturer
Phoenix Contact
Relay Input Amperage
3 Mamp
Relay Application
Input Function Output Function
Relay Load Voltage DC Rating
3 Volt - 48 Volt
Coil Voltage Rating
110-127 Volt
Features
Relay modules with safe isolation according to DIN EN 50178 between coil and contact
Time savings of up to 60 %
No need for additional modular terminal blocks
Efficient connection to system cabling using V8 adapter
Space savings of up to 80 %
Sensor connected directly to relay module
Functional plug-in bridges
Downloads
Phoenix 2900359 Application Note English.pdfPhoenix 2900359 CAD data International.dxfPhoenix 2900359 CAD data International.pdfPhoenix 2900359 CAD data International.stpPhoenix 2900359 Manufacturers declaration English.pdfPhoenix 2900359 Manufacturers declaration International.pdfPhoenix 2900359 Package Slip International.pdfPhoenix 2900359 Product Information English.pdfPhoenix 2900359 Tender Text English.zipPhoenix 2900359 Various International.pdf
