Phoenix Contact 3060186 Plug UP 4/ 8
Normally In Stock
Code: 63734
Phoenix 3060186 Terminal Plug Screw connection 800 V 32 Amp gray Terminal Blocks
Condition: New
Usually Ships Same day or Next Day$13.34
Sale Price
$11.12
MUST BUY IN PACKS OF 25
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3060186 The plug features an 800 V voltage rating and a nominal current capacity of 32 A. It has eight positions for connections and utilizes a screw connection method. The rated cross-sectional area is 4 mm2, but can vary between 0.2-6 mm2, while the color of the plug is gray.
Specifications
Terminal Block Voltage Rating
800 Volt
Terminal Block Component Color
Gray
Terminal Block Connection Method
Screw Connection
Terminal Block Min Wire Size
24
Terminal Block Max Wire Size
10
Terminal Block Amperage
32 Amp
Jumper Pitch
6.2 mm
Terminal Block Width
49.6 mm
Jumper Number of Positions
8
Manufacturer
Phoenix Contact
Component
Plug
Component
Terminal Plug
Features
Conductor connection from above
Screw actuation from the side
The plug design enables space-saving potential distribution by using four-conductor terminal blocks with two slots
Downloads
Phoenix 3060186 CAD data International.dxfPhoenix 3060186 CAD data International.pdfPhoenix 3060186 CAD data International.stpPhoenix 3060186 Manufacturers declaration English.pdfPhoenix 3060186 Manufacturers declaration International.pdfPhoenix 3060186 Safety note English.pdfPhoenix 3060186 Tender Text English.zip
