Schneider Electric NSYSBM15308 Spacial SBM Wall mounted Sheet Steel Enclosure - IP66, 5.91" x 11.81" x 3.15" (HxWxD)

Schneider Electric NSYSBM15308, part of the Spacial range, is a wall-mounted enclosure made of sheet steel with a gray RAL 7035 color finish. It features a captive screw PZ2 lock outside the sealed area, a polyester powder surface finish, and a plain door front cover fixed with half turn metal screws. The enclosure is suitable for use in temperatures ranging from -31 to 176 °F (-35 to 80 °C).

Specifications
Component	Steel Enclosure
Enclosure Depth	3.15"
Manufacturer	Schneider Electric
Enclosure Height	5.91"
Enclosure Mount Type	Wall Mount
Enclosure Composition	Steel
Enclosure Impact Rating	IK10
Enclosure Latch Type	Captive Screw
Enclosure Width	11.81"
Line	Spacial SBM
