Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Schneider Electric NSYPLM86TVG Thalassa PLM Wall mounted Fiberglass Reinforced Polyester Enclosure - IP66, 33.35" x 25.04" x 11.81" (HxWxD)
Normally In Stock
Code: 592156
Schneider Electric NSYPLM86TVG - Fiberglass Reinforced Polyester - 3 points lock, handle with 1242E key lock - IK08 - IP66 - : Window - Without Mounting Plate - 33.35" x 25.04" x 11.81" (HxWxD)
Condition: New
Usually ships Same Day or Next Day$754.99
Sale Price
$629.16
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric Thalassa PLM enclosure provides secure protection for electrical components. Its polyester-reinforced fibreglass body and tempered glass door offer durability. The front-accessible design and wall mounting provide easy operation and installation. With a 3-point lock and 1242E key lock handle, this enclosure ensures security. The transparent door display enhances visibility. It has a nominal depth of 11.81 in, a height of 33.35 in, and a width of 25.04 in. Certified with Class II electrical insulation and IK08 degree of protection, it offers reliable safety. The enclosure can withstand temperatures ranging from -40 to 176 °F.
Specifications
Enclosure Door Type
Window
Enclosure Depth
11.81"
Manufacturer
Schneider Electric
Enclosure Mount Type
Wall Mount
Component
Non-Metallic Enclosure
Enclosure Composition
Fiberglass Reinforced Polyester
Enclosure Impact Rating
IK08
Line
Thalassa PLM
Enclosure Mounting Plate
Without Mounting Plate
Enclosure Height
33.35"
Enclosure Width
25.04"
Enclosure Latch Type
3 Point Lock
Features
Thalassa PLM wall-mounting polyester enclosure monobloc w/glazed door
847 x 636 x 300 mm
Built-in canopy, one piece moulded with notches in the rear
Without mounting plate
2 locks (3 points lock, handle with 1242E key lock)
Accessible front
Polyester reinforced with fibreglass, tempered glass door
Grey RAL 7035
IP66, IK08, NEMA (13,4X) 960°C fire resistance.
