Schneider Electric NSYPLA5123G Thalassa PLA Floor-standing Fiberglass Reinforced Polyester Enclosure - NEMA 12/2/13/1, 19.69" x 49.21" x 12.6" (HxWxD)
Normally In Stock
Code: 592152
Schneider Electric NSYPLA5123G - Fiberglass Reinforced Polyester - 2 points lock, 5 mm double-bar - IK10 - NEMA 12/2/13/1 - 2 Door: Solid - 19.69" x 49.21" x 12.6" (HxWxD)
Condition: New
Usually ships Same Day or Next Day$780.35
Sale Price
$650.29
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric NSYPLA5123G is a Thalassa range enclosure made of polyester reinforced with fiberglass. It features a solid front door with a 2-point lock and a 5mm double-bar. The door can be removed by hinges, and the rear panel by a fixing element. The product offers accessibility for operation from the rear and front and has a floor-standing enclosure mounting. It meets NEMA 12, NEMA 2, NEMA 13, and NEMA 1 standards for degree of protection. With a nominal depth of 12.60 inches (320mm), a nominal height of 19.69 inches (500mm), and a nominal width of 49.21 inches (1250mm), this suitable enclosure provides a reliable solution. Additionally, it has an electrical insulation class of Class II, an IK degree of protection of IK10 IEC 62262 for a plain door, and offers fire resistance up to 1760 °F (960 °C) IEC 62208. The Thalassa PLA version ensures high-quality performance and durability.
Specifications
Enclosure Mount Type
Free-Standing
Enclosure Number of Doors
2 Door
Manufacturer
Schneider Electric
Enclosure Height
19.69"
Enclosure Depth
12.6"
Enclosure Door Type
Solid
Component
Non-Metallic Enclosure
Enclosure NEMA Rating
NEMA Type 12
Enclosure NEMA Rating
NEMA Type 13
Enclosure NEMA Rating
NEMA Type 1
Enclosure NEMA Rating
NEMA Type 2
Line
Thalassa PLA
Enclosure Width
49.21"
Enclosure Composition
Fiberglass Reinforced Polyester
Enclosure Impact Rating
IK10
Enclosure Latch Type
2 Point Lock
Features
Thalassa PLA floor standing polyester enclosure
500x 1250x 320 mm
Sealed top and bottom part, assembled with side parts
2 points lock, 5 mm double-bar insert
2 doors
Accessible front and rear
Right and left 120° opening
Polyester reinforced with fibreglass
Grey RAL 7035
IP65, IK10, NEMA (1,2,12,13)
960°C fire resistance.
