Ilsco ACMN-4/0 Pigtail Adaptor - Aluminum, Stranded, 600 V, Silver
Normally In Stock
Code: 588276
Ilsco ACMN-4/0 - Aluminum Compression Pigtail AdaptorConductor size 4/0, Tin Plated, cULus
Condition: New
CALL FOR LEAD TIME$71.19
Sale Price
$54.76
NO MOQ/PACK QUANTITY. QTY 1 = QTY 1
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Ilsco ACMN-4/0 - Aluminum Compression Pigtail Adaptor for 4/0 conductor size, Tin Plated, cULus listed. Dual rated for copper/aluminum conductors. Rated for 600V, 90°C. Includes insulating cover. DE-OX® technology. UL/cUL 486A/B Listed. Color coded with ink barrel marking. Compatible with Ilsco die index 298. Replacement cover available. 180° compression connection. Voltage rated without cover at 35 kV.
Specifications
Color
Silver
Manufacturer
Ilsco
Material
Aluminum
Maximum Operating Temperature (Fahrenheit)
194 °F
Maximum Operating Temperature (Celsius)
90 °C
Connector Finish
Tin
Voltage Rating
600 V
Number of Connectors
1
Component
Pigtail Adaptor
Features
Manufactured from high strength aluminum alloy
ACMN pin is center, ACON pin is off center
Chamfered barrel
cULus listed for 35KV, 90˚C
Clearly marked with wire size and die index for ILSCO tools, proper number & location of crimps
Prefilled with DE-OX®
Color coded end caps inserted in barrel
Supplied with insulating cover, cULus listed for 600 volts, 90˚C
