Ericson 83FRC Female Receptacle - Black, IP68, 13 Amp, 600 Volt
Normally In Stock
Code: 577071
Ericson 83FRC Mini-Sync Receptacle Female Straight 3 Pole 1ft Leads PVC - 12" x 9" x 2" (LxWxH)
Condition: New
Usually ships Same Day or Next DayMUST ORDER A MINIMUM OF $150 FROM ERICSON FOR PRODUCT TO SHIP
$46.80
Sale Price
$39.00
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Ericson 83FRC is a black, IP68 rated female Mini-Sync connector with a 1ft cable length. It is ideal for typical applications in conveyors, robotics, and transportation equipment. The connector has a single keyway and three poles, with a load capacity of 13A at 600VAC. The over molded body is made of PVC, while the contact sleeve is stainless steel. Wiring code is 1=Green, 2=Black, 3=White.
Specifications
Receptacle Color
Black
Receptacle Voltage
600 Volt
Component
Receptacle
Manufacturer
Ericson
Receptacle Number of Poles
3 Pole
Cable Length
1 Ft
Receptacle NEMA Type
Type 6P
Receptacle IP Rating
IP 68
Receptacle Max Wire Size
16 AWG
Receptacle Amperage
13 Amp
Features
NEMA 6P and IP68 Protection
Made in the USA
Compatible with U.S. and European sensors
High-impact resistant contact carriers
Corrosion resistant gold plated contacts
Secure pin and contact crimp termination
Mechanically keyed
Field installable
Stress and harsh environment resistant
Vibration resistant
Designed for low amperage AC or DC control systems
Wide range of configuration alternatives available including male and female connections, 2 thru 12 pole pin-outs, straight 90° configurations and single or dual keyway
