Code: 573441
Dwyer PE-N-3 Orifice Plate Flowmeter
Normally In Stock
Dwyer PE-N-3 - PVC orifice plate flowmeter, 10" line size, 7.000" bore, 0.7 Beta, air capacity: 8626.42 SCFM @ 14.7 psia, 14846.80 SCFM @ 20 psig, 28506.17 SCFM @ 100 psig; 6 lb.
Condition: New
Usually ships Same Day or Next Day$1829.39
Sale Price
$1524.49
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer PE-N-3 is a reliable Orifice Plate Flowmeter designed for measuring flow in clean air and compatible gases (PE) or compatible gases and liquids (TE). With an accuracy of ±0.6% full scale flow and a pressure limit of 150 psi, it is suitable for a range of applications. The wetted material is gray PVC for PE or white PTPE for TE, with Buna-N gaskets. The flowmeter is easy to install with a 1/4" female NPT process connection and 1/2" to 24" line size. It requires a standard flange 125#/150# rating for installation and has a head loss of 1 - Beta ratio². The flowmeter also meets pipe requirements of 10 diameter upstream and 5 diameter downstream.
Specifications
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
Component
Flow Meter
(Instrument-Sensor) Application
Air
(Instrument-Sensor) Type
Orifice Plate
(Instrument-Sensor) Measurement Accuracy
0.60%
(Instrument-Sensor) Temperature Range
PE: 140°F/60°C
(Instrument-Sensor) Temperature Range
TE: -40 - 200°F/-40 - 93.3°C
Manufacturer
Dwyer Instruments
Features
Mounted with standard flanges with no need of specialty flanges
Reduced installation costs with simple installation by slipping the unit between standard flanges
Easy access with corner type metering taps
Long operation life with corrosion free material
Proven through a wide range of applications for energy efficiency
PTFE construction yields excellent chemical and weather resistance
TE models are flame retardant without factory gaskets
Low friction leading to minimum wear and long operation life
