Code: 573439
Dwyer PE-M-3 Orifice Plate Flowmeter
Normally In Stock
Dwyer PE-M-3 - PVC orifice plate flowmeter, 8" line size, 5.600" bore, 0.7 Beta, water capacity: 320" d.p. W/C, 2195.86 GPM flow; air capacity: 5532.00 SCFM @ 14.7 psia, 9525.43 SCFM @ 20 psig, 18290.00 SCFM @ 100 psig; 5 lb.
Condition: New
Usually ships Same Day or Next Day$1274.56
Sale Price
$1062.13
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer PE-M-3 Orifice Plate Flowmeter is a reliable and accurate solution for measuring flow in clean air and compatible gases (PE) or compatible gases and liquids (TE). With a temperature range of -40 to 200°F and an accuracy of ±0.6% full scale flow, this flowmeter is ideal for a variety of applications. Its construction from monolithic PVC or PTPE ensures durability and its 1/4" female NPT process connection makes installation easy. With a pressure limit of 150 psi and a line size of 1/2" to 24", this flowmeter is a versatile choice for many industries. The head loss is calculated using the Beta ratio, allowing for accurate measurement. It also meets general requirements of 10 diameters upstream and 5 diameters downstream.
Specifications
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
Component
Flow Meter
(Instrument-Sensor) Application
Air
(Instrument-Sensor) Type
Orifice Plate
(Instrument-Sensor) Measurement Accuracy
0.60%
(Instrument-Sensor) Temperature Range
PE: 140°F/60°C
(Instrument-Sensor) Temperature Range
TE: -40 - 200°F/-40 - 93.3°C
Manufacturer
Dwyer Instruments
Features
Mounted with standard flanges with no need of specialty flanges
Reduced installation costs with simple installation by slipping the unit between standard flanges
Easy access with corner type metering taps
Long operation life with corrosion free material
Proven through a wide range of applications for energy efficiency
PTFE construction yields excellent chemical and weather resistance
TE models are flame retardant without factory gaskets
Low friction leading to minimum wear and long operation life
