Code: 573434
Dwyer PE-L-1 Orifice Plate Flowmeter
Normally In Stock
Dwyer PE-L-1 - PVC orifice plate flowmeter, 6" line size, 1.800" bore, 0.3 Beta, water capacity: 20" d.p. W/C, 49.46 GPM flow; air capacity: 187.86 SCFM @ 14.7 psia, 291 SCFM @ 20 psig, 531.75 SCFM @ 100 psig; 4 lb.
Condition: New
Usually ships Same Day or Next Day$944.17
Sale Price
$786.81
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer PE-L-1 Orifice Plate Flowmeter is a reliable and accurate flow measurement solution. With a temperature range of -40 to 200°F (-40 to 93.3°C) and an accuracy of ±0.6% full scale flow, it can handle clean air, compatible gases, and liquids. Constructed with gray PVC or white PTPE with Buna-N gaskets, this flowmeter is suitable for pressure up to 150 psi. It has a 1/4" female NPT process connection and can be installed with standard flange 125#/150# rating. The head loss is 1 - Beta ratio², and it requires 10 diameter upstream and 5 diameter downstream pipe requirements.
Specifications
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
Component
Flow Meter
(Instrument-Sensor) Application
Air
(Instrument-Sensor) Type
Orifice Plate
(Instrument-Sensor) Measurement Accuracy
0.60%
(Instrument-Sensor) Temperature Range
PE: 140°F/60°C
(Instrument-Sensor) Temperature Range
TE: -40 - 200°F/-40 - 93.3°C
Manufacturer
Dwyer Instruments
Features
Mounted with standard flanges with no need of specialty flanges
Reduced installation costs with simple installation by slipping the unit between standard flanges
Easy access with corner type metering taps
Long operation life with corrosion free material
Proven through a wide range of applications for energy efficiency
PTFE construction yields excellent chemical and weather resistance
TE models are flame retardant without factory gaskets
Low friction leading to minimum wear and long operation life
