Code: 573108
Dwyer MDS-11 Miniature Pressure Switch
Normally In Stock
Dwyer MDS-11 - Miniature pressure switch, set point 20.0" H2O.
Condition: New
Usually ships Same Day or Next Day$58.84
Sale Price
$49.03
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer MDS-11 is a miniature pressure switch designed for a temperature range of 40° to 150°F (4° to 66°C). Its enclosure is made of polycarbonate, with brass tab-type electrical connections for quick disconnections. It operates at a voltage of AD/DC - 30V or less with a resistive load. The pressure limit depends on the set point, with <3.0 in. H2O at 8 psi and >3.0 in. H2O at 15 psi. The switch type is SPST normally open, with two barbed ports for 1/8"-3/16" ID tubing. It has a gold contact switch with a maximum current rating of 40 mA resistive load, allowing for a life of over 20 million cycles. The switch can be used with air or compatible fluids on the "high" side, and the diaphragm is made of polyurethane.
Specifications
(Instrument-Sensor) Type
Miniature
Component
Pressure Switch
(Instrument-Sensor) Temperature Range
40° - 150°F/4° - 66°C
Manufacturer
Dwyer Instruments
Features
Low cost, long service life and fast response time is suitable for a wide range of OEM uses
Lightweight but shock and vibration resistant for tough applications
Gold contacts help ensure a clean connection without dirt or oxidation
