Dwyer PTGD-SA11A Differential Pressure Piston-Type Gauge
Normally In Stock
Code: 572471
Dwyer PTGD-SA11A - Differential piston gauge, in-line connections, range 0-100 psid.
Condition: New
Usually ships Same Day or Next Day$749.74
Sale Price
$624.78
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer PTGD-SA11A is a piston-type differential pressure gauge designed for accurate measurement in compatible gases and liquids. With a temperature range of up to 176°F (80°C) and an accuracy of ±2% FS, it can be mounted in any position. The wetted materials include aluminum or 316 SS for the gauge body, piston, and spring, with Buna-N as the standard seal. The gauge has a pressure limit of 3000 psi (206 bar) for aluminum body models and 6000 psi (413 bar) for SS body models. It has 1/4" female NPT end connections as standard, with back or bottom connections available. The dimensions are 2.5" (63 mm) or 4.5" (115 mm), and the window is made of acrylic.
Specifications
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
Component
Differential Pressure Gauge
(Instrument-Sensor) Temperature Range
176°F/80°C
(Instrument-Sensor) Type
Piston Type
(Instrument-Sensor) Measurement Accuracy
2.0%
Manufacturer
Dwyer Instruments
Features
Rugged, weather and corrosive proof design supports use in harsh environments
Over-protection range depending on model, up to 6000 psig (400 bar) allows high-pressure applications
Flexibility of connection selection fits the most sophisticated designs
