Code: 570254
Dwyer UV-5112 Ultra-View™ Polysulfone Flowmeter
Normally In Stock
Dwyer UV-5112 - Polysulfone flowmeter, range 4.0-40.0 GPM (20-150 LPM) water.
Condition: New
Usually ships Same Day or Next Day$661.33
Sale Price
$551.11
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer UV-5112 Ultra-View™ Polysulfone Flowmeter is a reliable option for measuring the flow of compatible liquids or gases. With a temperature range of 35 to 212°F (2 to 100°C), this flowmeter ensures accurate readings with ±2% FS accuracy at 70°F ±2°F (21.1°C) and 14.7 psia. It can handle pressure up to 150 psi and has a 1" female NPT process connection. The wetted material includes polysulfone body and fittings, fluoroelastomer O-rings, and virgin PTFE float. Repeatability is ±1% FS and it comes with scales ranging from 6" to 7". Fitting torque is a maximum of 22 ft lb.
Specifications
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
Component
Flow Meter
(Instrument-Sensor) Temperature Range
35 - 212°F/2 - 100°C
(Instrument-Sensor) Temperature Range
35 - 130°F/2 - 54°C
(Instrument-Sensor) Measurement Accuracy
2.0%
Manufacturer
Dwyer Instruments
(Instrument-Sensor) Type
Ultra-View Polysulfone
Features
Corrosion-resistant polysulfone body ideal for applications where other flowmeters fail saving replacement cost and time
Easy to clean body yields low maintenance costs
Polycarbonate shield protects internal scale increasing product operating life
Low installation costs with optional panel mount polysulfone fittings
