nVent Hoffman E4PBX4 Steel 30.5mm Push Button Extra Deep Steel Enclosure
Normally In Stock
Code: 56919
nVent Hoffman E4PBX4 10" x 4" x 4.75" Type 4,Type 12 Outdoor-Indoor 4 Hole 30.5-mm Push Button Extra Deep Steel Enclosure Yellow (DOES NOT INCLUDE BACK PANEL)
Condition: New
Usually ships Same Day or Next DayDOES NOT INCLUDE BACK PANEL
$295.80
Sale Price
$246.50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
nVent Hoffman E4PBX4 Steel 30.5mm Push Button Extra Deep Steel Enclosure Extra-Deep Pushbutton Enclosure, designed to hold 30.5-mm and 22.5-mm pushbuttons and switches, feature stainless steel screws and a high-performance polyurethane gasket to meet Type 4 environmental protection rating. The added depth accommodates additional pushbutton contact blocks.
Specifications
Enclosure Environment Rating
Outdoor-Indoor
Enclosure Hinge Type
Standard Hinge
Enclosure Interior Color
Gray
Enclosure Composition
Painted Steel
Enclosure Depth
4.75"
Enclosure Door Type
Pushbutton 30.5 mm
Enclosure NEMA Rating
NEMA Type 4
Enclosure Width
4"
Component
Push Button Enclosure
Enclosure Height
10"
Enclosure Latch Type
Screw
Push Button Number
4
Enclosure Number of Doors
1 Door
Enclosure NEMA Rating
NEMA Type 12
Manufacturer
Hoffman
Features
High-performance polyurethane gasket
Grounding stud on body
Bonding provision on cover
Factory stamped 4-way pushbutton holes
Captivated stainless steel cover screws thread into sealed wells
Seams continuously welded and ground smooth
Enclosures 6.00 x 4.00 x 5.00 in. (152 x 102 x 127 mm) and larger have internal detachable hinge to hold cover open during wiring, yet permit immediate removal
External wall-mounting brackets
30.5-mm or 22.5-mm size holes
