Littelfuse KSDU811200 is a digital time delay relay with a 1 A steady state output load rating and 10 A inrush at 60°C. It features 0.25 in. (6.35 mm) male quick connect terminals for easy installation. With an input AC line frequency of 50/60 Hz and a ±20% input tolerance, it operates at a humidity of 95% relative non-condensing. It offers a repeat accuracy of ±0.5% or 20 ms, whichever is greater. The relay is encapsulated and has a time delay tolerance of ±10%. It has a dielectric breakdown of ≥2000V terminals to mounting surface. The output voltage drop is approximately 2.5 V at 1 A. It has a digital time delay type and a recycle time of ≤150 ms. The minimum output holding current is ≤40 mA.
