Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 5100
nVent Hoffman ED1PBM1 Steel 22.5mm Drawn Top Push Button Enclosure
nVent Hoffman ED1PBM1 4.5" x 3" x 2.62" Type 4,Type 12,Type 13 Outdoor-Indoor 1 Hole 22.5-mm Push Button Gray Steel Enclosure (DOES NOT INCLUDE BACK PANEL)
Condition: New
Usually ships Same Day or Next DayDOES NOT INCLUDE BACK PANEL
$104.17
Sale Price
$86.81
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
nVent Hoffman ED1PBM1 Steel 22.5mm Drawn Top Push Button Enclosure Drawn 22.5-mm Pushbutton Enclosure Type 4 are designed to hold 22.5-mm 4-way pushbuttons and switches. No welded seams or sharp corners. For outdoor or indoor use.
Specifications
Enclosure Environment Rating
Outdoor-Indoor
Enclosure Interior Color
Gray
Enclosure Composition
Painted Steel
Enclosure Depth
2.62"
Enclosure Door Type
Pushbutton 22.5 mm
Enclosure NEMA Rating
NEMA Type 4
Enclosure Height
4.5"
Enclosure Width
3"
Component
Push Button Enclosure
Enclosure Latch Type
Screw
Push Button Number
1
Enclosure Number of Doors
1 Door
Enclosure NEMA Rating
NEMA Type 12
Enclosure NEMA Rating
NEMA Type 13
Manufacturer
Hoffman
Features
Grounding stud on body
Cover screws outside gasket sealing surface
Flat or domed flanged cover
Bonding provision on cover
No welded seams or sharp corners
Drawn enclosure
Oil-resistant gasket
30.5-mm or 22.5-mm size holes
Factory stamped 4-way pushbutton holes
External welded-on mounting brackets for easy installation
Downloads
Hoffman ED1PBM1 2D DXF CAD.zipHoffman ED1PBM1 3D STEP CAD.zipHoffman ED1PBM1 CAD Drawing.zipHoffman ED1PBM1 Declaration of Compliance.pdfHoffman ED1PBM1 Dimension Drawing.gifHoffman ED1PBM1 EU Certification.pdfHoffman ED1PBM1 Instruction Manual.pdfHoffman ED1PBM1 Repainting Instructions.pdfHoffman ED1PBM1 Spec Sheet.pdfHoffman ED1PBM1 UL Certification.pdfHoffman ED1PBM1 User Manual.pdf
