Schneider Electric SH30551P12F2100, Specification:,- Amps: 2.9,- Electrical Connection: Rotatable right angled connector,- Phase: Three phase,- Type of cooling: Natural convection,- Maximum mechanical speed: 9000 rpm,- Maximum radial force Fr: 340 N @ 1000 rpm, 270 N @ 2000 rpm, 240 N @ 3000 rpm, 220 N @ 4000 rpm, 200 N @ 5000 rpm, 190 N @ 6000 rpm, 180 N @ 7000 rpm, 170 N @ 8000 rpm,- Length: 6.26 in (159 mm),- Circle diameter of the mounting holes: 2.48 in (63 mm),- Shaft diameter: 0.35 in (9 mm),- Rotor inertia: 0.08 kg.cm²,- Continuous stall torque: 3.72 lbf.in (0.42 N.m) @ 115-480 V three phase,- Motor flange size: 2.17 in (55 mm),- Shaft end: Parallel key,- Holding brake: With,- Centring collar depth: 0.08 in (2 mm),- Number of mounting holes: 4,- Usually ships Same Day or Next Day *NON-CANCELLABLE, NON-RETURNABLE*minal speed: 9000 rpm @ 480 V three phase, 2000 rpm @ 115 V single phase, 8000 rpm @ 230 V single phase, 8000 rpm @ 400 V three phase,- Peak stall torque: 13.28 lbf.in (1.5 N.m) @ 115-480 V three phase,- Shaft length: 0.79 in (20 mm),- Maximum axial force Fa: 40 N,- Mounting holes diameter: 0.22 in (5.5 mm),- Usually ships Same Day or Next Day *NON-CANCELLABLE, NON-RETURNABLE*minal torque: 4.43 lbf.in (0.5 N.m) @ 115 V single phase, 4.43 lbf.in (0.5 N.m) @ 230 V single phase, 3.10 lbf.in (0.35 N.m) @ 400 V three phase, 3.10 lbf.in (0.35 N.m) @ 480 V three phase,- Centring collar diameter: 1.57 in (40 mm),- Stator resistance: 41.8 Ohm,- Usually ships Same Day or Next Day *NON-CANCELLABLE, NON-RETURNABLE*minal output power: 100 W @ 115 V single phase, 210 W @ 230 V single phase, 400 W @ 400 V three phase, 440 W @ 480 V three phase,- Continuous stall current: 0.73 A,- Stator inductance: 108.72 mH,- Back emf constant: 40 V/krpm @ 68 °F (20 °C),- Torque constant: 0.58 N.m/A @ 248 °F (120 °C),- Number of motor poles: 3,- Speed feedback resolution: 128 periods,- Continuous power: 290 W,- Encoder type: Absolute multiturn SinCos Hiperface,- Holding torque: 7.08 lbf.in (0.8 N.m),- Key width: 0.12 in (3 mm)
