Schneider Electric LXM32CD12N4 motion servo drive, Lexium 32, 12A, three phase, supply voltage 208 to 480V, 0.9kW, modbus
Normally In Stock
Code: 494759
Schneider Electric LXM32CD12N4 motion servo drive, Lexium 32, 12A, three phase, supply voltage 208 to 480V, 0.9kW, modbus *We recommend adding a reactor to mitigate harmonics and protect the drive from surges.
Condition: New
Usually ships within 3 business days$2084.44
Sale Price
$1737.03
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric LXM32CD12N4 is a three-phase servo drive designed for compatibility with various servo motors. It has a rated supply voltage of 200-240V and 380-480V, with a maximum continuous power of 800W at 230V and 1600W at 400V. The drive features an integrated fan for cooling and supports a switching frequency of 8 kHz. It is equipped with Modbus communication interface and comes in a compact size of 10.63 inch (270 mm) height, 9.33 inch (237 mm) depth, and 1.89 inch (48 mm) width. It meets EN/IEC 61800-5-1 and EN/IEC 61800-3 standards and offers safety functions such as STO (safe torque off). The drive is suitable for various industrial applications requiring precise motion control.
Specifications
VFD Amperage Output
12 Amp
Option Card Slots
Modbus
Manufacturer
Schneider Electric
VFD Input Voltage
480 Volt Three Phase
VFD Output Voltage
480 Volt Three Phase
Option Card Slots
Integrated
VFD Horsepower Output
2.1 HP
Features
Lexium 32 range provides the drive and motor combinations for right power, performance and functionality
Three book-size servo drive models and two servo motor families plus a full range of intelligent options
Lexium 32 simplifies all aspects in the machine lifecycle from engineering to maintenance
