Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 1300613 Device terminal block PTVFIX 2,5-3L/N/GNYE
Normally In Stock
Code: 492760
Phoenix Contact PTVFIX 2,5-3L/N/GNYE - Distribution block - 450 Volt, 24 Amp, 3 positions - 1300613
Condition: New
Usually Ships Same day or Next Day$3.61
Sale Price
$3.01
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1300613 A device terminal block features a nominal voltage of 450 V and a nominal current capacity of 24 A, accommodating up to 10 connections, with each position designed for push-in connection. The cross-sectional area ranges from 0.14 mm2 to 4 mm2, allowing for flexible mounting options such as direct mounting with a flange, free-hanging, or snapping onto a DIN rail adapter in various colors including gray/blue and green-yellow.
Specifications
Terminal Block Number of Connections
10
Terminal Block Amperage
24 Amp
Terminal Block Voltage Rating
450 Volt
Terminal Block Component Color
Gray/Blue/Green/Yellow
Manufacturer
Phoenix Contact
Sub Component
Distributor Terminal Block
Terminal Block Width
25.98 mm
Features
Fast installation with ready-to-connect distribution blocks and device terminal blocks
Significant space savings due to the minimal size
Flexible mounting options with various mounting adapters and special adhesive versions
Color-coded assignment of conductors and terminal points for intuitive and safe installation
Standardized accessories – the blocks can be extended, tested, and marked with the CLIPLINE complete accessories without any loss of pitch
